| HOME > 후렉시블조인트 > Vaccum Type Tube |
 |
Vaccum Type Tube |
|
| |
|
| |
 |
| 규격 |
형번 |
I.D |
O.D |
THICKNESS |
| 6A |
6P |
6.1 |
10.0 |
0.10 |
| 8A |
8P |
8.1 |
13.8 |
0.10 |
| 10A |
10P |
10.3 |
16.4 |
0.10 |
| 15A |
15P |
12.0 |
16.0 |
0.12 |
| 20A |
NEW16 |
20.0 |
29.0 |
0.12 |
| 25A |
NEW25 |
27.0 |
36.0 |
0.15 |
| 40A |
NEW40 |
41.5 |
54.0 |
0.20 |
| 50A |
NEW50 |
50.0 |
65.0 |
0.20 |
| 65A |
NEW65 |
65.3 |
86.0 |
0.25 |
| 80A |
NEW80 |
76.5 |
98.0 |
0.25 |
| 100A |
NEW100 |
101.0 |
125.0 |
0.25 |
|
| |
 |
| |
| |
| |
| |
| |
| |
|
